| Power supply |
:: 24VDC 2A |
|
| Maximum Power Consumption |
:: 48VA |
|
| Input Port Type |
:: 24VDC Sink Type, OptoIsolator |
|
| Output Port Type |
:: Relay Type (220Vac 5A Max) |
|
| IO Status Indicator |
:: LED Red color |
|
| Memory Backup |
:: Battery 3.0V |
|
| Communication |
:: RS232C |
|
| Number of IO Port |
:: Max 96 points (Input 48 points, Output 48 points) |
|
| Memory device type |
:: User program, parameter : EEPROM (8 Kbytes) Data : SRAM (32 Kbytes) |
|
 |
||
| Program control method |
:: Cyclic execution of stored program |
|
| I/O processing method |
:: Updated after scan |
|
| Program capacity |
:: 2048 Step |
|
| Protocal |
:: LG Master-K Compatible |
|
| Memory device range |
:: P : I/O relay / P000-P05F (96 points) M : Internal Buffer relay / M000-M31F (512 points) K : Keep relay / K000-K15F (256 points) L : Link relay / L000-L15F (256 points) F : Special relay / F000-F15F (256 points) T : 100ms timer / T000-T095(96 points), 10ms timer / T096-T127(32 points) Nonvolatile Area : T072-T127 C : Counter / C000-C127(128 points) Nonvolatile Area : C096-C127 D : Word data register (16bit) D000-D255(256words) Nonvolatile Area:D0192-D0255 |
|
| Counter |
:: Up counter, Down counter, Up-Down counter Ring counter (Counter range : 0-65535) |
|
| Timer |
:: On delay timer, Off delay timer (Timer preset value : 0-65535) |
|
| High Speed Counter | :: Not implement | |
บริษัท
เฟริสท์เฟลก
กรุ๊ป จำกัด
FirstFlex Group Co.,Ltd
59/617 Nimitr mai Rd., Samwatawan-aok, Klong-sam-wa, Bangkok 10510
59/617 ถนนนิมิตรใหม่ แขวงสามวาตะวันออก เขตคลองสามวา กรุงเทพ 10510
Tel : 662-9157272, +662-9157273 Fax : +662-9156740
© copyright Companyname
JTC series is PLC which is designed by ourself.
Just we know your requirement/application, we can respond yours at the point.
